Main Technical Features
Equipped with a dry-type air filter, good filtering effect and convenient maintenance.
Clutch disc made of imported high-strength powder metallurgy material, hightransmission capacity and reliable performance.
Independent oil circuit for the hydraulic system, high cleanliness and low failure rate.
Full hydraulic steering system, steering wheel adjustable forward and backward, reducing labor intensity.
Vertical double-cylinder forced soil-insertion lifter, large lifting force and goodoperation adaptability
Equipped with an extra-large capacity diesel fuel tank, long continuous operationtime and high efficiency.
Our tractor Equipped with a well-known high-quality engine, large power reserve, low fuel consumption and high economic benefit. Multi-state variable frequency switch is optional, providing different power for different working conditions to meet the requirements of fuel saving andefficiency improvement.
| Model | LTB504/LTB604 LTB7041 | LTB704 | LTB804 | LTB904 | LTB1004 | LTB1204 |
| Drive Type | 4wd | |||||
| Overall Dimension (Mm) | 3925×1728×2870 | 4070×1750×2870 | 4080×1750×2880 | 4230×1750×2820 | 4315×1750×2820 | |
| Min. Operating Weight(Kg) | 2565 | 2565 | 2720 | 2820 | 3000 | 3100 |
| Rated Traction Force (N) | 18050 | 18050 | 20605 | 20700 | 31010 | 31010 |
| Wheel Tread (Front/Rear) | 1265/1320 | 1265/1320 | 1265/1350 | 1285/1350 | 1420/1352 | 1353/1352 |
| Wheel Base (Mm) | 2010 | 2010 | 2030 | 2030 | 2070 | 2070 |
| Min. Ground Clearance (Mm) | 360 | 360 | 370 | 370 | 400 | 400 |
| Min. Turning Radius (M) | ≤4.3 | |||||
| Theoretical Speed (Forward) | 2.32~30.96 | 2.32~30.96 | 2.41~30.96 | 2.51~32.26 | 2.51~32.26 | 2.51~32.26 |
| Theoretical Speed (Reverse) | 2.04~27.14 | 2.04~27.14 | 2.04~27.14 | 2.20~28.27 | 2.20~28.27 | 2.20~28.27 |
| Engine Type | Vertical, Water Cooled, Four Stroke, Direct Injection | |||||
| Number Of Cylinders | 4 | |||||
| Engine Rated Speed (R/Min) | 2400 | |||||
| Engine Rated Power (Kw) | 36.8/44.1/51.5 | 51.5 | 59 | 66.2 | 73.5 | 88.3 |
| Clutch | Single,Dry Type,DualFunction | |||||
| Gear Box | 4×3×(1+1) | |||||
| Main Drive | Spiral Bevel Gearing | |||||
| Differential | Closed,4 Planetary Bevel Gears | |||||
| Differential Lock | Mechanical Locking Differential | |||||
| Final Drive | Single Planetary Gear | |||||
| Tyre (Front) | 8.320 | 8.324 | 8.324 | 8.324 | 9.524 | 9.524 |
| Tyre (Rear) | 1132 | 1132 | 1132 | 14.930 | 14.930 | 14.930 |
| Steering Gear | Front Wheel Hydraulic Steering | |||||
| Brake | Wet Type, Disc Brake | |||||
| PTO Speed (R/Min) | 540/760 Or 540/1000 | |||||
| PTO Spline Size | 6 Splines Or 8 Splines | |||||
| Max. Lifting Force (Kn) | 12700 | 12700 | 16700 | 16700 | 21005 | 22010 |
| 3Point Suspension | Category: II | |||||
*The parameter shall be subject any change without additional notice.
A: In stock-- 3-5 working days.
B: Normal engine brand--7-10 working days.
C: Specified engine brand-15-30 working days.
D: Tractor with front loader---extra 12-15 working days.
30% advanced payment by T/T, 70% balance payment against loading container by T/T.
The warranty period is 12 months, since the date of loading container. The spare parts (broken not caused by man-made) and quick-wear parts are not included.
The warranty period is 12 months, since the date of loading container. The spare parts (broken not caused by man-made) and quick-wear parts are not included.
How about the loading container (for reference)?
| 3035hp tractor | 20GP: 68 sets | 40HQ: 1216 sets (in SKD) |
| 4065hp tractor | 20GP: 2 sets | 40HQ: 34 sets |
| 70130hp tractor | 40HQ: 24 sets | |
| 140-260hp tractor | 40HQ: 12 sets |
