Main Technical Features
Our tractor Equipped with a well-known high-quality engine, large power reserve, low fuel consumption and high economic benefit. Multi-state variable frequency switch is optional, providing different power for different working conditions to meet the requirements of fuel saving andefficiency improvement.
| Model | LTS2004 | LTS2204 | LTS2404 | LTS2604 | |
| Tractor Parameters | Drive Type | 4WD | |||
| Overall Dimensions (mm) | 5840×2470×3220 | 5840×2470×3220 | 5840×2470×3220/ 5840×3465×3220 (4 rear tires) | 5840×3465×3220 (4 rear tires) | |
| Min. Operating Mass (kg) | 8200 | 8200 | 8250/8400 (4 rear tires) | 8400 (4 rear tires) | |
| Rated traction Force (N) | 68110 | 68110 | 68110 | 73000 | |
| Wheel tread (Front/Rear) | 2030/1900 | 2030/1900 | 2030/1900，2030/2330 (4 rear tires) | 2030/2330 (4 rear tires) | |
| Wheelbase (mm) | 3000 | 3000 | 3000 | 3000 | |
| Min. Ground Clearance (mm) | 445 | 445 | 445 | 445 | |
| Min. Turning Radius (m) | ≤7 | ≤7 | ≤7 | ≤7 | |
| Theoretical Speed (Forward) | 0.26～30.72 | 0.26～30.72 | 0.26～30.72 | 0.26～30.72 | |
| Theoretical Speed (Reverse) | 2.63～26.06 | 2.63～26.06 | 2.63～26.06 | 2.63～26.06 | |
| Engine | Engine Type | Vertical, Water cooled, four stroke, direct injection | |||
| Number of cylinders | 6 | 6 | 6 | 6 | |
| Engine Rated speed (r/min) | 2200 | 2200 | 2200 | 2200 | |
| Engine Rated power (kW) | 147 | 162 | 177 | 191.5 | |
| Transmission System | Clutch | Single, dry type, Dual Action | |||
| Gear box | 4×4×2×（1+1） | ||||
| Main drive | Spiral bevel gearing | ||||
| Differential | Closed, 4 planeatry bevel gears | ||||
| Differential lock | Spiral bevel gearing | ||||
| Final drive | Single planeatry gear | ||||
| Traveling System | Tyre (front) | 16.9-28 | 16.9-28 | 16.9-28 | 16.9-28 |
| Tyre (rear) | 20.8-38 | 20.8-38 | 20.8-38 | 20.8-38 | |
| Steering gear | Front wheel hydraulic steering | ||||
| Brake | Wet type, disc brake, hydraulic control | ||||
| Working Device | PTO Speed (r/min) | 540/1000 or 760/1000 | |||
| PTO Spline Size | 21 splines | ||||
| Max. Lifting Force (kN） | 49000 | 49000 | 49500 | 50000 | |
| 3-Point suspension | Category: III | ||||
*The parameter shall be subject any change without additional notice.
A: In stock-- 3-5 working days.
B: Normal engine brand--7-10 working days.
C: Specified engine brand-15-30 working days.
D: Tractor with front loader---extra 12-15 working days.
30% advanced payment by T/T, 70% balance payment against loading container by T/T.
The warranty period is 12 months, since the date of loading container. The spare parts (broken not
caused by man-made) and quick-wear parts are not included.
The warranty period is 12 months, since the date of loading container. The spare parts (broken not caused by man-made) and quick-wear parts are not included.
How about the loading container (for reference)?
| 3035hp tractor | 20GP: 68 sets | 40HQ: 1216 sets (in SKD) |
| 4065hp tractor | 20GP: 2 sets | 40HQ: 34 sets |
| 70130hp tractor | 40HQ: 24 sets | |
| 140-260hp tractor | 40HQ: 12 sets |
