Main Technical Features
Our tractor Equipped with a well-known high-quality engine, large power reserve, low fuel consumption and high economic benefit. Multi-state variable frequency switch is optional, providing different power for different working conditions to meet the requirements of fuel saving andefficiency improvement.
| Model | LTX1504 | LTX1604 | LX1804-1 | LTX2004-1 | |
| Tractor Parameters | Drive Type | 4WD | |||
| Overall Dimensions (mm) | 5211×2350×3140 | 5211×2350×3140 | 5211×2350×3140 | 5211×2350×3140 | |
| Min. Operating Mass (kg) | 5900 | 5900 | 5950 | 6050 | |
| Rated traction Force (N) | 56600 | 56600 | 56800 | 57000 | |
| Wheel tread (Front/Rear) | 1980/1662 | 1980/1662 | 1980/1662 | 1980/1662 | |
| Wheelbase (mm) | 2688.5 | 2688.5 | 2688.5 | 2688.5 | |
| Min. Ground Clearance (mm) | 460 | 460 | 460 | 460 | |
| Min. Turning Radius (m) | ≤7.3 | ≤7.3 | ≤7.3 | ≤7.3 | |
| Theoretical Speed (Forward) | 0.29～30.45 | 0.29～30.45 | 0.29～30.45 | 0.29～30.45 | |
| Theoretical Speed (Reverse) | 0.62～14.22 | 0.62～14.22 | 0.62～14.22 | 0.62～14.22 | |
| Engine | Engine Type | Vertical,Water cooled, four stroke, direct injection | |||
| Number of cylinders | 6 | 6 | 6 | 6 | |
| Engine Rated speed (r/min) | 2200 | 2200 | 2200 | 2200 | |
| Engine Rated power (kW) | 110.3 | 117.7 | 132.4 | 147 | |
| Transmission System | Clutch | Dry type,dual-function,independent operation | |||
| Gear box | 4×（3+1）×2 | 4×（3+1）×2 | 4×（3+1）×2 | 4×（3+1）×2 | |
| Main drive | Spiral bevel gearing | ||||
| Differential | Closed, 4 planeatry bevel gears | ||||
| Differential lock | Mechanical locking differential | ||||
| Final drive | Single planeatry gear | ||||
| Traveling System | Tyre (front) | 14.9-26 | 14.9-26 | 14.9-26 | 14.9-26 |
| Tyre (rear) | 18.4-38 | 18.4-38 | 18.4-38 | 18.4-38 | |
| Steering gear | Full hydraulic steering | ||||
| Brake | Wet type, disc brake, hydraulic control | ||||
| Working Device | PTO Speed (r/min) | 540/1000 or 760/1000 | |||
| PTO Spline Size | 6 splines or 8 splines 38mm | ||||
| Max. Lifting Force (kN） | 31800 | 35500 | 38500 | 40500 | |
| 3-Point suspension | Category: II | Category: III | |||
*The parameter shall be subject any change without additional notice.
A: In stock-- 3-5 working days.
B: Normal engine brand--7-10 working days.
C: Specified engine brand-15-30 working days.
D: Tractor with front loader---extra 12-15 working days.
30% advanced payment by T/T, 70% balance payment against loading container by T/T.
The warranty period is 12 months, since the date of loading container. The spare parts (broken not caused by man-made) and quick-wear parts are not included.
The warranty period is 12 months, since the date of loading container. The spare parts (broken not caused by man-made) and quick-wear parts are not included.
How about the loading container (for reference)?
| 3035hp tractor | 20GP: 68 sets | 40HQ: 1216 sets (in SKD) |
| 4065hp tractor | 20GP: 2 sets | 40HQ: 34 sets |
| 70130hp tractor | 40HQ: 24 sets | |
| 140-260hp tractor | 40HQ: 12 sets |
